Bandwidth Limits

The first technology that limits the number of viewers supported by a camera system is Internet bandwidth. At the location where your DVR or camera is located, you need a high speed Internet connection to support remote viewing. Typically businesses use cable, DSL, or a T1 for their Internet connection. Ask your service provider what the maximum upload speed is for your Internet connection or run a speed test from a PC at the location. The upload speed is the one you want to note.

Software Limits

The second technology that limits the number of remote users supported is the software of the DVR or IP camera software. Network DVRs and IP cameras both use embedded web server software to serve video streams to client applications, web browsers, and mobile apps. Just as a web server used to host web sites is limited in the number of users that can access a web page, the web servers built into surveillance equipment limited by the number of video streams it can serve simultaneously. Users need to also consider that the software of your DVR is also performing other resource intense operations such as recording video and managing all of the configurations rules related to recording and alarms.

Hardware Limits

Last, there is the limitation of the hardware. Even the fastest supercomputers available have limits to the number of processes they can handle at any given time. Most entry and mid-level surveillance DVRs use processors equivalent to the Atom processor, like the ones use in tiny netbook computers. And again, these processors need to handle a lot of important tasks such as continuously recording multiple video streams, activating recording based on alarm events like motion detection, and allowing users to playback and export recorded video. It is easy to see why these devices are limited in the number of remote users and video streams they can serve.

Max Remote Viewers for Surveillance DVRs

When shopping for a surveillance system, keep in mind that not all DVRs and IP cameras are created equal. Higher end DVRs have faster processors and more memory. In addition, some manufacturers build better software than others. Below are a few stand alone (embedded) DVRs and PC based DVRs with varying numbers of simultaneous remote viewer support. Please note that some manufacturers limit the number of total users that can be logged in and others limit the total number of video streams that can be served.

• iDVR-E4, iDVR-E8, iDVR-E16 and iDVR-RT16 surveillance DVRs can support up to 3 simultaneous remote viewers.
• iDVR-PRO8 and iDVR-PRO16 CCTV DVRs can support up to 5 simultaneous remote viewers.
• Geovision PC based DVRs can serve 200 video channels simultaneously. So for example, if you have 5 cameras being accessed at the same time for all users, the Geovision system can support 40 simultaneous users.
• The NUUO NVRmini network video recorder can server 32 channels simultaneously.
• NUUO PC Based DVRs and NVRs supports 128 video streams of remote viewing

If you have any questions related to remote viewing surveillance DVRs or anything else related to video surveillance, please contact CCTV Camera Pros at 561-433-8488.

1. Port forwarding is not properly setup on the router that the camera is connected to. Port forwarding allows outside Internet traffic to the surveillance camera. More details can be found here about how port forwarding works.
2. The IP address of the Internet connection at the location of the camera is not being used. If you are accessing your camera using an IP address that starts with 192. or 10., then you are using the LAN (local area network) IP address of the device, which will only work on the local network.

These problems are easily solved by doing the following.

1. Follow the instructions for your router to setup port forwarding for the port that your camera uses for remote access. A very typical default port is 80. Port forwarding instructions for some routers can be found here. If your router is not on that page, the concepts are the same to configure any router and you should be able to improvise if you have the manual for your particular model. Once you have port forwarding setup, you can use this check port forwarding tool to be sure that you did successfully set it up correctly.
2. Make sure you know the correct Internet IP address used at the location where your camera is. From a computer that is
   on the same network as your camera, use this what is my IP address tool to verify that you know your correct WAN address.
3. Use the IP address obtained in the step above to configure the the client software that you are using to access your camera. In this case, the iCamViewer iPhone app can access your camera both from WIFI and 3G internet connections.

More Help Available
We hope that this article was useful in helping to troubleshoot the mobile access to your surveillance camera. If you need additional help, please post to our surveillance iPhone app forum.

• Zavio CamGraba 32 channel NVR software
• Zavio CamGraba Android App

The below screen shots show the single camera and six camera view that is available in the app. When users have more that 6 cameras on their system, they can access additional views of their cameras by swiping their finger on the screen to page through the views of their cameras.

Main App Features

• View up to 32 cameras in live view display at QCIF resolution
• Full screen single channel live view display at CIF resolution
• Support taking snapshots
• Support for Physical / Digital PTZ control
• Support Digital IO

In addition to Android, Zavio also plans on releasing the CamGraba iPhone app very soon. The interface will be almost identical to the Android interface. CCTV Camera Pros also has the iCamViewer iPhone app available which works with Zavio IP cameras and does not require the Windows NVR software to work. The iCamViewer connects directly to the IP camera instead of the NVR software.

About CCTV Camera Pros
CCTV Camera Pros is a master distributor for Zavio located in Palm Beach, Florida. CCTV Camera Pros sells Zavio and other video surveillance equipment for home, business, and government installations. For any questions related to this article or anything related to IP or CCTV camera equipment, please contact us.

• Compatible with all ZAVIO models, including VGA, 1.3 megapixel and 2 megapixel
• Remote 4-channel live view and playback simultaneously
• Motion detection & scheduled recording
• Supports H.264/ MPEG-4/ MJPEG compression formats
• Multiple user access levels with password protection
• Powerful recording search functions

Click here for to download complete list of all NVR features and product specification.

For more information on Zavio IP cameras and to download the CamGraba NVR software, please visit:
www.cctvcamerapros.com/Zavio-IP-Cameras-s/404.htm

About CCTV Camera Pros
CCTV Camera Pros is a direct supplier of security cameras and video surveillance systems for home, business and government applications. We are a US veteran owned business located in Boynton Beach, Florida. CCTV Camera Pros is a master distributor for Zavio and can assist in the design of surveillance systems for any size application. Please visit www.cctvcamerapros.com to learn more about us and the surveillance products that we supply.

The iDVR-E series video surveillance DVRs are used with CCTV cameras and include a free Mac software application that lets users manage and connect to one or more of these DVRs from a Mac desktop or laptop PC. The Mac DVR software allows the user to view the live video in real time and also playback recorded video remotely over the Internet. The user interface is easy to use and very powerful. This is one of the best Mac DVR clients that we have seen and we have confirmed that the software is compatible with the Mac Lion and Mac Snow Leopard OS. Please click on the below image to view additional screenshots of the Mac software included with the iDVR-E.

If your goal is to setup an IP security camera and log in directly to it from the web browser of your Mac, Zavio IP cameras are an excellent choice. CCTV Camera Pros has tested and confirmed that Zavio cameras can be accessed from Safari, Firefox, and Chrome web browsers on a Mac computer using Lion or Snow Leopard operating systems. Please click on the below image to view additional screenshots and demo videos of Zavio IP cameras being access remotely over the Internet using Mac.

About CCTV Camera Pros
CCTV Camera Pros is a direct supplier of security cameras and video surveillance systems for home, business and government applications. We are a US veteran owned business and are located in Boynton Beach, Florida. CCTV Camera Pros can assist in the design of surveillance systems for any size application. We specialize in assisting our customers not only in the selection of the best equipment for their needs but also in remote support and setup of the Internet access to their cameras. Please visit www.cctvcamerapros.com to learn more about us and the surveillance products that we supply.

Commenting on the the new CCTV surge protectors, Mike Haldas, managing partner of CCTV Camera Pros says, “Being located in South Florida, we are all too familiar with the damage that lightning strikes can cause. The SP-S1 and SP-R16 surge protectors are extremely popular to use in locations where there is a risk of power surges from lightning strikes. We think that it is worth the additional investment to install surge protectors when running coaxial cable to protect valuable video equipment. CCTV Camera Pros has increased our supply of these devices recently to make them even more affordable.”

At the time of this writing, the SP-S1 single channel protector is available for $19.99. The SP-R16 16 channel rack mountable protector is available for $289.99. Please click to visit this page for additional information and to purchase.

Commenting on the iCamViewer, CCTV Camera Pros co-founder and appliction architect Mike Haldas says: “I have personally used the iCamViewer to monitor a construction project at my house. My wife and I added a loft to our house last year and I used Vivotek IP cameras and network video servers on the site to monitor what was going on. Not only was it nice to be able to see the progress of the project whenever I wanted to, but it gave me some peace of mind to be able to keep an eye on the workers that were in my home when I was not there. I am very happy that we are able to offer this app for free to users around the world.”

Some screen shots of the iCamViewer app being used with Axis IP cameras can be seen below. Please click on any of the images for a larger view.

For additional information about the iCamViewer and to download the app for free, please visit:
http://itunes.apple.com/us/app/icamviewer-cctv-camera-ip/id346469891?mt=8

Mobile CMS App for iPhone

The iDVR is the best CCTV DVR in its price range that has the type of high end quality and remote viewing support that it does. The iDVR is exclusively sold by CCTV Camera Pros and is available in 4, 8, and 16 channel models. There is a free mobile CMS iPhone app that is compatible with the iDVR that allows users to view their cameras remotely in single screen view as well as 4, 8, and 16 camera view grids on one screen. The quality of this app is the best that we have seen for a stand alone recorder. The app connects to the DVR’s H.264 video stream which enables very fast response time even over slower Internet connections. In addition to supporting remote view for iPhone, the app also works in 2x display mode for iPad and an app is also available for Android and Blackberry smart phones. If you want to view from a laptop or desktop computer, both Windows and Mac computers are supported. The iDVR pricing currently starts at $599 for the 4 channel model.

Click here to view an image gallery and demonstration videos of he remote iPhone viewing capability of the iDVR.

Click here to download the mobile CMS iPhone app for iDVR.

Geovision GV-Eye iPhone App

If you already have a DVR that you do not want to replace but it is missing support for iPhone access, then a Geovision GV-VS04H IP video server and the GV-Eye iPhone app may be the perfect solution for you. The GV-VS04H allows you to connect up to 4 CCTV cameras to it. The video server enables access to your cameras from the iPhone using the free GV-Eye app. Users can easily split the video signals from each of their cameras between their existing DVR and the Geovision video server. Click here to view video server installation options. The GV-Eye iPhone app supports viewing one or 4 cameras per screen and also supports connecting to multiple video servers and Geovision IP cameras. This allows users to view multiple locations from the same app session.

Click here to watch a video demonstration of the GV-Eye App connecting to a Geovision video server.

Click here to download the GV-Eye iPhone app.

About the Author
This article was written by Mike Haldas, co-founder and managing partner at CCTV Camera Pros. Mike is a subject matter expert in the area of video surveillance and mobile software applications. Before starting CCTV Camera Pros with business partner Greg Bond, Mike worked as an Internet software engineer and product manager. Mike has a passion for finding and testing the best video surveillance equipment and software applications available so that CCTV Camera Pros can provide them to their customers. If you have questions about this article or anything related to video surveillance systems and mobile viewer apps, Mike can be contacted at mike@cctvcamerapros.net.

iPhone CCTV App Screenshot

The below screenshot shows the new iDVR app being used from the Apple iPhone 4.

Please click on the image for a larger view.

iPad CCTV App Screenshot

The below screenshot shows the new iDVR app being used from the Apple iPad one.

Please click on the image for a larger view.

iPhone & iPad DVR Viewer App Demo Video

The below video demonstrates the new iDVR app using an iPad in portrait and landscape views. The app looks exactly the same on an iPhone.

For more information and pricing on the iDVR-E4, iDVR-E8, and iDVR-E16 model CCTV DVRs that are compatible with the mobile CMS app, please click here: iDVR H.264 Stand Alone DVRs.

Customers that have any questions about the new iDVR app or who wish to request a demo on their iPhone or iPad can contact CCTV Camera Pros sales toll free at 888-849-2288 or by emailing info@cctvcamerapros.net.

This original article can be viewed on CCTV Camera Pros blog here: “iPad & iPhone CCTV App Enables Remote DVR Viewer Access”.

Commenting on the PTZ-WIR12X, CCTV Camera Pros cofounder Mike Haldas says: “We are extremely excited to offer a high quality infrared pan tilt zoom camera that does not break the bank. Our customers have been asking for an IR pan tilt zoom model that costs less than $2000 and with the WIR12X CCTV Camera Pros has handily beat that expectation. We are rolling this new model out this week at a retail price of $1199. I believe that this represents a great value compared to the other options that we have seen on the market. Our quality assurance team has tested this camera with our iDVR stand-alone digital video recorders as well as our Geovision and NUUO PC based surveillance DVRs. The results were outstanding. Users can see the videos that were created from our QA testing on our website. This camera will integrate well with any DVR that uses Pelco D protocol for pan tilt zoom communications.”

The PTZ-WIR12X is currently available on CCTV Camera Pros website for $1199.99. For additional information and a complete specification of this PTZ, please visit:
www.cctvcamerapros.com/IR-PTZ-Camera-p/ptz-wir12x.htm

To view online video demonstrations using this pan tilt zoom camera in day and night time mode operations, please visit:
www.cctvcamerapros.com/IR-PTZ-Camera-p/ptz-wir12x.htm#Pan-Tilt-Zoom-Camera-Demo-Videos

About CCTV Camera Pros
CCTV Camera Pros is a direct supplier of security cameras and video surveillance systems for home, business and government applications. We are a US veteran owned business and are located in Boynton Beach, Florida. CCTV Camera Pros can assist in the design of surveillance systems for any size application. Please visit www.cctvcamerapros.com to learn more about us and the surveillance products that we supply.

The VM-16RT is currently available from CCTV Camera Pros (at the time this article was written) for $499.99. Please click for additional information or to buy online: 16 Channel CCTV Multiplexer.

Commenting on the VM-16RT, CCTV Camera Pros co-founder Mike Haldas says: “CCTV Camera Pros is very happy to offer the new VM-16RT. I believe that we are providing a great value by offering a real-time 16 channel video processor at a price point of under $500. CCTV multiplexers and quad processors are still extremely useful in many video surveillance systems today. CCTV Camera Pros sales engineers continue to find handy uses for video multiplexers in modern surveillance systems that have complex video display requirements or display requirements that go beyond what a typical surveillance DVRs supports. We also find that some customers are using cameras only for live viewing, where no video recording is involved in the application. In addition to this, there are still a lot of VCR surveillance recorders deployed that need a replacement video mux when a legacy one goes bad. We will continue to supply the best video multiplexers for as long as our customers need them.”

Video Mux Features

• 16 Channel BNC Video Inputs / 16 BNC Loop Out / 4 Channel Audio RCA Inputs
• 1 BNC Monitor, 1 BNC VCR Out, 1 BNC VCR In, 1 RCA Audio Out
• Real time refresh rate
• Supports NTSC and PAL Video
• Separate Color Adjustments for each Security Camera
• Brightness, Contrast, Saturation, Hue, and Sharpness
• Selectable Video Display Modes: 16 Camera Grid, 9 Camera Grid, 8 Camera Grid, Quad Screen, Full Screen, Picture in Picture, Dual Screen (2 camera split screen), Auto sequence
• Image Freeze Function
• Selectable Image Zoom Area
• Text Overlay Information per Camera: Camera Title, Time & Date
• Wireless Remote Control Included
• Power Supply Included

16 Channel CCTV Multiplexer Video

The following video demonstrates the capability of the VM-16RT video mux using a 42″ LCD monitor and four surveillance cameras.

About CCTV Camera Pros

CCTV Camera Pros is a supplier of complete video surveillance systems and individual security components for home, business and government. CCTV Camera Pros is a veteran owned business founded by a United States Marine and is located in Boynton Beach, Florida in Palm Beach County. CCTV Camera Pros can assist in the design of surveillance systems for any size application. Please visit CCTV Camera Pros website to learn more about us and the products we supply: www.cctvcamerapros.com.

Original Article

This article was originally posted on CCTV Camera Pros blog. Click here to view the original article “Video Mux Provides 16 Channel CCTV Multiplexer“.

The VM-Q401A is available online from CCTV Camera Pros at the time of this writing for $129.99. Please click here for more information or to purchase online: VM-Q401A CCTV color quad processor.

Commenting on the VM-Q401A, CCTV Camera Pros co-founder and managing partner Mike Haldas says: “CCTV Camera Pros finds that quad processors and video multiplexers for CCTV still have a place in many video surveillance systems today. There are still many systems deployed that are using legacy VCR surveillance recorders which need a reliable partner for replacement parts. In addition to this, our surveillance engineers find uses for quad processors many times for use when customers have display requirements that go beyond what typical surveillance DVRs support. We also find that some customers are using cameras not for recording, but instead just for live viewing. Our new color quad processor helps us meet our customer’s requirements in all of these cases. One feature that stands out on this new unit is the split screen function. Many older video processors do not offer a 2 camera split screen display mode. This and the thin wireless remote that is included with our model, set it apart from others on the market and we are proud of that.”

CCTV Quad Processor Features

• 4 Channel BNC Video Inputs / 4 Channel Audio RCA Inputs
• 1 BNC Monitor, 1 BNC VCR Out, 1 BNC VCR In, 1 RCA Audio Out
• Real time refresh rate
• High Resolution Video
• 720×480 60Hz for NTSC
• 720×576 50Hz for PAL
• Separate Color Adjustments for each Security Camera
• Brightness, Contrast, Saturation, Hue, and Sharpness
• Selectable Video Display Modes: Quad Screen, Full Screen, Picture in Picture, Dual Screen (2 camera split screen), Auto
• sequence
• Image Freeze Function
• Selectable Image Zoom Area
• Text Overlay Information per Camera: Camera Title, Time & Date
• Playback in Quad or Full Screen when used with Surveillance VCR
• Wireless Remote Control Included
• Power Supply Included

CCTV Quad Product Demo Video

The following video demonstrates the VM-Q401A CCTV color quad processor’s video processing capability on a 42″ LCD monitor using 4 CCTV cameras.

About CCTV Camera Pros

CCTV Camera Pros is a supplier of security cameras and video surveillance systems for home, business and government use. CCTV Camera Pros is a veteran owned business founded by a United States Marine. CCTV Camera Pros can assist in the design of surveillance systems for any size application. Please visit CCTV Camera Pros website to learn more about us and the products we supply: www.cctvcamerapros.com.

iDVR-PRO iPhone App Setup

To setup the an iDVR-PRO8 or iDVR-PRO16 CCTV DVR to be accessible from the iCamViewer, users can follow these instructions.

1. Connect the iDVR-PRO to your network router and switch
2. Configure port forwarding on your router so that your DVR can be accessed from outside of your local network. If you need help with this step, please refer to this page for port forwarding instructions.
3. Please note that the default port for the iDVR-PRO is 8080
4. It is recommend that you test the Internet access from the safari web browser in your iPhone to confirm that port forwarding and the connection is working properly before configuring the iCamViewer app.
5. After you confirm that the connectivity is setup correctly through Safari, download the iCamViewer app from iTunes.
6. Open the app on your iPhone, iPod touch, or iPad device and click on the Config button in the My Cams section of the app.
7. Fill in all of the configuration fields:
   Name: This is any name you want for your camera.
   Host or IP: This is the public (not LAN) IP address where your iDVR-PRO is located. If you are using a DynDNS service, you can enter the hostname here.
   Port: 8080 is the default port
   Username: ADMIN is the defaul username
   Password: 1234 is the default password
   Manufacturer: Choose CCTV Camera Pros
   Models: Choose iDVR-PRO8 or iDVR-PRO16
8. Tap the check box in the upper right
9. Your camera should come into view

iCamViewer App Setup Screen

Click image for larger view

iCamViewer Viewing iDVR-PRO Surveillance DVR Screenshots

The below screenshots show the iCamViewer app being used to access an iDVR-PRO8. 4 CCTV cameras are connected to this particular DVR. The user is able to click the DVR Channel select wheel to switch to the 4 different cameras connected to this DVR. The user can swip his finger across the screen to access other DVRs or IP cameras if additional devices are configured.

Please click on any of the below images to access a larger image view.

CCTV Camera Pros would like to thanks our partners at AppBurst for the awesome mobile application development services that they have provided in co-developing the iCamViewer with us. In addition to developing great mobile applications for surveillance, they also have one of the best development platforms to develop iPhone and iPad apps for events and conferences.

About CCTV Camera Pros

CCTV Camera Pros is a supplier of security cameras and video surveillance systems for home, business and government use. We are a veteran owned business founded by a United States Marine and are located in Palm Beach, Florida. CCTV Camera Pros can assist in the design of surveillance systems for any size application. Please visit CCTV Camera Pros website to learn more about us and the products we supply: www.cctvcamerapros.com.

Commenting on the MON-LCD25P, CCTV Camera Pros co-founder and managing partner Mike Haldas says: “Our customers have been asking for a hand-held CCTV test monitor that also provides power to a camera for a while and we are very excited that we now have a manufacturing partner producing the MON-LCD25P for us to our specification and quality assurance standards. There are several test monitors on the market but none at this affordable price point that use the battery of the tester to also power the security camera being tested. Our product development team continues to listen to the demands of our customers and deliver the product solutions that they ask us for. I am very proud of how CCTV Camera Pros continues to adapt to market demands.”

The LCD25P comes complete with the following: 2.5” LCD hand-held test monitor, quick release neck strap, rechargeable battery with power supply, coaxial test cable with RCA and BNC connectors, camera power supply cable, and instruction manual. Click here for additional information about the MON-LCD25P portable CCTV test monitor.

About CCTV Camera Pros
CCTV Camera Pros is a supplier of security cameras and video surveillance systems for home, business and government use. We are a veteran owned business founded by a United States Marine and are located in Palm Beach, Florida. CCTV Camera Pros can assist in the design of surveillance systems for any size application. Please visit CCTV Camera Pros website to learn more about us and the products we supply: www.cctvcamerapros.com.

Funny Surveillance Video

More About Live Wildlife Cams
CCTV Camera Pros supplies surveillance equipment for wildlife cam projects. CCTV Cameras can be used to stream video live using services like uStream and LiveSTream. A project that CCTV Camera Pros recently donated cameras for was the “Living in the Lions Den” live camera event where a man is living with Lions for 30 days.

About CCTV Camera Pros
CCTV Camera Pros is a supplier of security camera systems for home, business, and government use. CCTV Camera Pros is a veteran owned business and GSA contract holder. CCTV Camera Pros has a complete line of surveillance products including security cameras, digital video recorders, monitors, cables, connectors, and all accessories needed for a complete video surveillance systems. CCTV Camera Pros can help design systems for any type and size application. Please visit www.cctvcamerapros.com to learn more.

Newly Integrated and compatible D-Link IP Cameras

• DCS-900
• DCS-910
• DCS-920
• DCS-6620G
• DCS-2100
• DCS-2120
• DCS-3220
• DCS-5300G

D-Link iPhone App Screenshot

The following image was captured while the iCamViewer app was viewing a DCS-6620G IP camera. Please click on the image for a larger view.

About the iCamViewer

iCamViewer from CCTV Camera Pros is a free iPhone and iPad app that allows you to view up to IP security cameras and CCTV cameras from your iPhone. iCamViewer is compatible with IP camera manufacturers such as Vivotek, Zavio, Axis, D-Link, LinkSys, Cisco, Mobotix, and StarDot. The iCamViewer app also works with CCTV cameras when used with a compatible network videos server. Click here for more information and to download the iCamViewer IP camera iPhone app for free.

About CCTV Camera Pros

CCTV Camera Pros is a supplier of security camera systems for home, business, and government use. CCTV Camera Pros is a veteran owned business and GSA contract holder. CCTV Camera Pros has a complete line of video surveillance products including security cameras, digital video recorders, monitors, cables, connectors, and all accessories needed for a complete video surveillance systems. CCTV Camera Pros can help design systems for any type and size application. Please visit www.cctvcamerapros.com to learn more.

Lions Den Live Video Stream

This outdoor CCTV camera was used to capture this recording.

Please click on this link for additional details and pricing on the BIPRO-S600VF12 outdoor surveillance camera available from CCTV Camera Pros.

CCTV Cameras for Live Wildlife Camera Use

For organizations interested in setting up live wildlife cameras or any type of live streaming camera for Ustream, CCTV Camera Pros can help by providing high quality CCTV Cameras that can be used with streaming services like uStream and LiveStream. CCTV Camera Pros supplies cameras at a discount and in some cases donates free cameras to non-profit organizations that are doing great things, as we believe the Wildlife Habitat of Hernando Florida is doing. Please call us at 888-849-2288 if you are interested in setting up a wildlife camera. You can also email us at info@cctvcamerapros.net or visit our main website here: CCTV Camera Pros.

About WROH
Wildlife Rehabilitation of Hernando (WROH) was formed 11 years ago here in Spring Hill, Florida. It was set up to provide a place for injured or orphaned wildlife to be brought to, given medical treatment, food and a chance to recover before being released back into the wild. Orphaned animals are taken care of and taught to be able to survive in the wild, and then given a soft release. Red fox, gray fox, raccoons, opossums, flying squirrels, grey squirrels, fox squirrels, bobcats, snakes, turtles, coyotes, eagles, owls, hawks, ducks, deer and alligators are some of the animals that have been helped along in their life. For more information, please visit: www.wrohflorida.com.

About CCTV Camera Pros
CCTV Camera Pros is a supplier of security camera systems for home, business, and government use. CCTV Camera Pros is a veteran owned business and GSA contract holder. CCTV Camera Pros has a complete line of surveillance products including security cameras, digital video recorders, monitors, cables, connectors, and all accessories needed for a complete video surveillance systems. CCTV Camera Pros can help design systems for any type and size application. Please visit www.cctvcamerapros.com to learn more.

Commenting on the iCamViewer, CCTV Camera Pros managing partner Mike Haldas says, “CCTV Camera Pros iPhone apps development team continues to add additional IP camera models from manufactures around the world to our list of iCamViewer supported cameras. Our team is adding additional network camera models on a weekly basis. This is based on requests from users around the world which can be made from inside the app. We are very excited about the integration with Mobotix cameras. Mobotix is one of the largest manufacturers of megapixel security cameras in the world. As iPhone and iPad users continue to make requests to add additional devices, we will continue to respond to their requests as quickly as possible. CCTV Camera Pros has a goal to have the best free camera viewer iPhone app in the world.”

The iCamViewer has been tested with the Mobotix model D12 camera. Being that Mobotix cameras all use a standard interface and software development kit (SDK), the iCamViewer should work with all Mobotix camera models. Users should make sure that the JPEG image URL is enabled for their camera if they are having trouble with the app. Users that need help can email support at icamviewer@cctvcamerapros.net. Below is a screenshot that was taken when CCTV Camera Pros tested integration with the Mobotix D12.

Click on the image for a larger view.

Free IP Camera Viewer iPhone App

Click here to download iCamViewer, the free security camera viewer app.

About CCTV Camera Pros
CCTV Camera Pros is a global supplier of security camera systems for home, business, and government use. CCTV Camera Pros is a veteran owned business and GSA contract holder. CCTV Camera Pros has a complete line of surveillance products including security cameras, digital video recorders, monitors, cables, connectors, and all accessories needed for a complete video surveillance systems. CCTV Camera Pros can help design systems for any type and size application. Please visit www.cctvcamerapros.com to learn more.

iPhone App & iPad App Axis Compatible Cameras

The following Axis cameras and Axis network video servers have been tested and confirmed to be compatible with the iCamViewer iPhone app:

• 207MW
• M1031-W
• M1054
• 210
• P1311
• P1346
• 211
• 211M
• 221
• 221 Night
• Q1755
• 209MFD
• 216FD
• 216MFD
• 225FD
• M3014
• P3301
• P3344
• Q7401

Although not every Axis camera model has been tested, it is believe that the iCamViewer iPhone application will work with all models.

Axis Camera iPhone App Images

The following screenshots where taken from actual testing of the Axis P1346 and 216FD cameras.

Download FREE Axis Compatible iPhone App

To download the iCamViewer app for free and for more information, please visit:
http://www.cctvcamerapros.com/CCTV-Camera-iPhone-App-s/362.htm

About iCamViewer

iCamViewer from CCTV Camera Pros is a free iPhone and iPad app that allows you to view up to 8 IP security cameras from your iPhone. iCamViewer is compatible with IP camera manufacturers such as Vivotek, Zavio, Axis, and StarDot. The iCamViewer app also works with CCTV cameras when used with a compatible network videos server.

About CCTV Camera Pros

CCTV Camera Pros is a manufacturer and distributor of video surveillance systems for home, business and government use. CCTV Camera Pros is a veteran owned business founded by a United States Marine. CCTV Camera Pros has a complete line of surveillance products including security cameras, digital video recorders, monitors, cables, connectors, and all accessories needed for a complete video surveillance systems. CCTV Camera Pros can help design systems for any size application. CCTV Camera Pros is partnered with a network of over 600 installers in the United States to provide surveillance system installation to all areas of the USA. Please visit CCTV Camera Pros website to learn more about us and the products that we supply.

The iDVR-PRO already accessible from the Safari web browser from iPhones, however it was not very convenient for users to always have to type in the URL of their DVR and enter their login information. Now, users can save their DVR and camera settings in the iCamViewer app and just launch the app when they want to view their cameras.

iCamViewer iPhone App iDVR PRO Setup

To setup the an iDVR-PRO recorder to be accessible from the iCamViewer, users can follow these instructions.

1. Connect the iDVR-PRO to your network router and switch
2. Configure port forwarding on your router so that your DVR can be accessed from outside of your local network. If you need help with this step, please refer to this page for port forwarding instructions.
3. Note: the default port for the iDVR-PRO is 8080
4. It is recommend that you test the Internet access from the safari web browser in your iPhone to confirm that port forwarding and the connection is working properly before configuring the iCamViewer app.
5. After you confirm that the connectivity is setup correctly through Safari, download the iCamViewer app from the app store.
6. Open the app on your iPhone or iPad and click on the Config button in the My Cams section of the app.
7. Fill in all of the configuration fields:
   Name: This is any name you want for your camera.
   Host or IP: This is the public (not LAN) IP address where your iDVR-PRO is located. If you are using a DynDNS service, you can enter the hostname here.
   Port: 8080 is the default port
   Username: ADMIN is the defaul username
   Password: 1234 is the default password
   Manufacturer: Choose CCTV Camera Pros
   Models: Choose iDVR-PRO Cam 1 to view camera 1, iDVR-PRO Cam 2 for camera 2, so on and so forth
8. Tap the check box in the upper right
9. Your camera should come into view

iCamViewer App Setup Screen

Click image for larger view

Compatible with IP Cameras

The iCamViewer app is also compatible with Zavio and Vivotek IP cameras. For a complete list of compatible IP cameras and pricing information please visit the iCamViewer Compatible IP Cameras Page

iPhone App Compatible with CCTV Cameras

In addition to supporting the iDVR PRO, the iCamViewer is also compatible with CCTV cameras by using a compatible network IP server or CCTV Camera Pros iDVR-PRO CCTV DVR.

About CCTV Camera Pros

CCTV Camera Pros is a manufacturer and distributor of video surveillance equipment for home, business and government use. CCTV Camera Pros is a veteran owned business founded by a United States Marine. CCTV Camera Pros has a complete line of surveillance products including security cameras, digital video recorders, monitors, cables, connectors, and all accessories needed for a complete video surveillance systems. CCTV Camera Pros can help design systems for any size application. CCTV Camera Pros is partnered with a network of over 600 installers in the United States to provide surveillance system installation to all areas of the USA. Please visit CCTV Camera Pros website to learn more about us and the products that we supply.
